Electrical (1)
Exploded diagram and parts list for Yamaha 40HP Electrical (1) (E40GMHL – 2003)
Parts List
| Ref | Part No | Description | Qty | |
|---|---|---|---|---|
| 1 | 6F5-81916-00 | Cover, Terminal | Add to Inquiry | |
| 2 | 90164-06M01 | Screw, Tapping | Add to Inquiry | |
| 3 | 6F5-85542-01 | Bracket | Add to Inquiry | |
| 4 | 6F5-82317-00 | Damper, Ignition Coil | Add to Inquiry | |
| 5 | 90387-08M45 | Collar | Add to Inquiry | |
| 6 | 97075-08030 | Bolt | Add to Inquiry | |
| 7 | 92995-08600 | Washer | Add to Inquiry | |
| 8 | 95380-06600 | Nut, Hexagon | Add to Inquiry | |
| 9 | 6F5-85540-22 | C.D.I. Unit Assy | Add to Inquiry | |
| 10 | 90164-06M01 | Screw, Tapping | Add to Inquiry | |
| 11 | 6F6-85530-00 | Ignition Coil Assy | Add to Inquiry | |
| 12 | 62E-82371-11 | Cap, Plug | Add to Inquiry | |
| 13 | 90465-11M10 | Clamp | Add to Inquiry | |
| 14 | 97095-06025 | Bolt | Add to Inquiry | |
| 15 | 92995-06600 | Washer | Add to Inquiry | |
| 16 | 6F5-85590-21 | Control Unit Assy | Add to Inquiry | |
| 17 | 6F5-82131-00 | Band, Battery | Add to Inquiry | |
| 18 | 688-82560-10 | Thermo Switch Assy | Add to Inquiry | |
| 19 | 6F5-82519-00 | Wire, Earth Lead | Add to Inquiry | |
| 20 | 97095-06016 | Bolt | Add to Inquiry | |
| 21 | 92995-06600 | Washer | Add to Inquiry | |
| 22 | 6F5-82588-00 | Plate | Add to Inquiry | |
| 23 | 6F5-81922-00 | Grommet | Add to Inquiry | |
| 24 | 90446-10M01 | Hose (L60) | Add to Inquiry | |
| 25 | 6F5-83622-81 | Mark | Add to Inquiry |
