Crankshaft & Piston
Exploded diagram and parts list for Yamaha 40HP Crankshaft & Piston (E40GMHL – 2003)
Parts List
| Ref | Part No | Description | Qty | |
|---|---|---|---|---|
| 1 | 6F6-11400-01 | Crankshaft Assy | Add to Inquiry | |
| 2 | 6F5-11412-11 | Crank 1 | Add to Inquiry | |
| 3 | 6F5-11422-11 | Crank 2 | Add to Inquiry | |
| 4 | 6F5-11432-11 | Crank 3 | Add to Inquiry | |
| 5 | 6F5-11442-11 | Crank 4 | Add to Inquiry | |
| 6 | 93306-307U0 | Bearing | Add to Inquiry | |
| 7 | 93332-000UE | Bearing | Add to Inquiry | |
| 8 | 93306-306U2 | Bearing | Add to Inquiry | |
| 9 | 6F5-11515-00 | Seal, Labyrinth | Add to Inquiry | |
| 10 | 93440-68M03 | Circlip | Add to Inquiry | |
| 11 | 6F5-11651-00 | Rod, Connecting | Add to Inquiry | |
| 12 | 6F5-11681-00 | Pin, Crank | Add to Inquiry | |
| 13 | 90209-27M07 | Washer | Add to Inquiry | |
| 14 | 93310-727V7 | Bearing | Add to Inquiry | |
| 15 | Piston | Add to Inquiry | ||
| 16 | Piston Ring Set | Add to Inquiry | ||
| 17 | 6F5-11633-00 | Pin, Piston | Add to Inquiry | |
| 18 | 663-11634-00 | Clip, Piston Pin | Add to Inquiry | |
| 19 | 93603-21111 | Pin, Dowel | Add to Inquiry | |
| 20 | 90201-20417 | Washer, Plate | Add to Inquiry |
