Optional Fuel Tank
OEM Suzuki DF6A Optional Fuel Tank exploded diagram and genuine part numbers.
Parts List
| Ref | Part No | Description | Qty | |
|---|---|---|---|---|
| 1 | 65000-99100 | Tank Assy, Fuel (12L) | Add to Inquiry | |
| 2 | 65520-99100 | Cap, Fuel Tank | Add to Inquiry | |
| 3 | 65561-95D00 | Gasket | Add to Inquiry | |
| 4 | 65740-99100 | Plug, Fuel Connector | Add to Inquiry | |
| 5 | 65831-95D00 | Filter Outlet | Add to Inquiry | |
| 6 | 65890-99100 | Outlet Assy | Add to Inquiry | |
| 7 | 65892-95D00 | O Ring | Add to Inquiry | |
| 8 | 65700-94JD1 | Hose, Fuel | Add to Inquiry | |
| 9 | 65750-87JL0 | Socket, Fuel Hose | Add to Inquiry | |
| 10 | 65750-98505 | Socket, Fuel Hose | Add to Inquiry | |
| 11 | 65770-99J01 | Pump, Squeeze | Add to Inquiry | |
| 12 | 65781-98500 | Clip, Fuel Hose | Add to Inquiry |
