Upper Casing
Exploded diagram and parts list for Yamaha 8HP Upper Casing (E8DMHL – 2003)
Parts List
| Ref | Part No | Description | Status | Price | |
|---|---|---|---|---|---|
| 1 | 677-45111-01-4D | Casing, Upper | ₹ — | Add | |
| 2 | 677-45113-A1 | Gasket, Upper Casing | ₹ — | Add | |
| 3 | 93605-08041 | Pin, Dowel | ₹ — | Add | |
| 4 | 97095-06025 | Bolt | ₹ — | Add | |
| 5 | 92995-06600 | Washer | ₹ — | Add | |
| 6 | 647-45151-01 | Cover, Upper Casing | ₹ — | Add | |
| 7 | 97095-06020 | Bolt | ₹ — | Add | |
| 8 | 92995-06600 | Washer | ₹ — | Add | |
| 9 | 93700-06M03 | Nipple, Grease | ₹ — | Add | |
| 10 | Extension | ₹ — | Add | ||
| 11 | 93604-08062 | Pin, Dowel | ₹ — | Add | |
| 12 | 97095-06020 | Bolt | ₹ — | Add | |
| 13 | 92995-06600 | Washer | ₹ — | Add | |
| 14 | 655-45318-00 | Bushing, Drive Shaft | ₹ — | Add | |
| 15 | 93420-26M00 | Circlip | ₹ — | Add |
